Custom electrical steel stator laminations and assembled stator cores manufactured to customer drawings for industrial, appliance and auxiliary motor projects. Slot form, tooth geometry, bore, outside diameter, mounting features, material and stack height are reviewed together before tooling and quotation.
Drawing and configuration review
- Tooth and slot geometry
- Bore, outside diameter and locating features
- Electrical-steel grade and thickness
- Stack height and assembly method
- Drawing revision and critical tolerances
Available delivery formats
Projects may be reviewed for loose stator laminations or drawing-approved stacked cores. Interlocking, riveting, welding, bonding or another assembly route is confirmed for the specific part rather than assumed.
Inspection planning
- Bore and outside-diameter measurement
- Tooth, slot and locating-feature inspection
- Burr, flatness and appearance checks
- Stack-height and assembly verification
- Sample report and buyer approval gate
Typical applications
- Industrial motors and drives
- Pumps, fans and rotating equipment
- Appliance and auxiliary motors
- Drawing-based custom motor platforms
Information required for quotation
- 2D or 3D drawing and revision
- Material grade and nominal thickness
- Critical dimensions and tolerances
- Loose or assembled delivery format
- Prototype and annual quantity
- Inspection, packing and destination requirements
Final tooling, material, heat-treatment route, assembly, inspection criteria, quantity and lead time are confirmed after engineering review.
Review the motor core manufacturing process or send a stator drawing.
